ACEY ACEY-HFC250 Automatic Cylindrical Battery Film Coating Machine With Heat Drying Function (0～120mm/sec)

Coating method: Flat coating, standard MRX-TM100 film maker (can be enlarged), optional scraper, wire rod and other gauges (manual scraping)

The coating width is adjustable from 6.4-100mm, the coating stroke is about 250mm, and the stroke is steplessly set and adjusted on the touch screen

Coating drive: Motor drive, coating speed is steplessly set and adjusted on the touch screen

Coating speed: 0～120mm/sec (such as lithium iron phosphate slurry)

Vacuum plate: Aluminum plate with vacuum

Vacuum plate size: L365mm × W200mm × H32mm

Scraper adjustable range: 0～6mm adjustable

Accuracy: ±3μm, optional 1μm dial indicator display

Heating drying system: Room temperature ~ 150℃, digital display temperature controller, accuracy ±1℃

Includes 1 built-in oil-free vacuum pump

Power supply: 220V/50Hz

Weight: 50KG

Dimensions: L505mm × W355mm × H325mm

1. Using large area uniform heating to ensure high precision and uniform temperature in the cavity.

2. Flat coating, motor-driven scraper coating, stable and adjustable coating speed.

3. The coating film speed is adjustable. The vacuum aluminum pan can quickly place or remove copper foil.aluminum foil, etc., built-in vacuum pump or connected to an external vacuum source, and the substrate is adsorbed without deformation.

4. Standard film dispenser, high coating precision, coating Adjustable cloth thickness.

5. Can be used in the glove box, easy to operate and small in size, which can save space.

6. PLC. Touch screen control for easy parameter setting.
