ACEY ACEY-D1000 5000A Pneumatic Gantry Spot Welding Machine Cylindrical Pack Welder

Energy Storage Capacitor: 6600UF

Maximum Transformer Output Power: 18KVA

Maximum Output Short Circuit Current: 5000A

Pre-welding Voltage: 80.0V–330V adjustable, accuracy 0.5V

Welding Voltage: 80.0V–330V adjustable, accuracy 0.5V

Welding Time: 1.0ms–20.0ms adjustable, accuracy 0.1ms

Applicable Scope: Maximum parallel welding thickness 0.03mm–0.15mm; maximum upper and lower butt welding thickness 0.1mm + 0.3mm

Machine Weight: 40KG

Dimensions: 350L × 180W × 280H mm

Input Power Supply: Single-phase AC220V/50Hz

Input Current: <5A

Input Power: <1200W

Features

1. Manual operating, easy to use: LCD display, keyboard adjustment, accurate, direct-viewing and convenient.

2. Microcomputer digital control, precision welding, energy is adjustable to accommodate a variety of welding requirements.

3. Precision controlled discharge time (photoelectric control system).

6. Controlled by micro-computer single chip microcomputer, the current regulation is fine, the output current is stable.

7. After-sales maintenance rate is low, maintenance is convenient.
