Charging Function: With constant current and constant voltage charging function
Discharge Function: With constant current and current limiting discharge function
Charge and Discharge Interface: Fully supports same-port charging/discharging and separate charging/discharging of battery packs, compatible with 2-wire (P+ P-) and 3-wire (P+ P- C-) configurations
USB Interface: Equipped with USB interface
Application: Used with barcode scanner to collect battery pack ID numbers for convenient data query after battery aging
Safety Protection: Anti-reverse connection protection function
Voltage Protection: Upper and lower voltage limit protection setting
Safe Discharge Current Protection: Maximum current 10A
Charging Requirements:
Charging Voltage: 0–100V, continuously adjustable, accuracy ±1mV (high precision dedicated)
Charging Current: 0–10000mA, continuously adjustable, accuracy ±1mA (high precision dedicated)
Discharge Requirements:
Discharge Voltage: 0–100V, accuracy ±1mV (high precision dedicated)
Discharge Current: 0–10000mA, accuracy ±1mA (high precision dedicated)
Discharge Current: 0–20A, accuracy ±1mA (high precision dedicated)
The test items include battery charging protection voltage, discharging protection voltage, capacity, etc. The equipment has four test steps: charging, discharging, shelving and cycling. By editing the corresponding step, the battery can be tested according to the set process.
