AARONIA SPECTRAN HF RSA 6000 Remote controllable Spectrum Analyzer (10Mhz – 6GHz)
ManufacturerAARONIA(View more products from this manufacturer)
ModelRSA6000
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
- Frequency range: 10MHz to 6GHz
- DANL: -135dBm(1Hz)
- DANL with Preamp: -150dBm(1Hz)
- Max. power at RF input: +10dBm
- Lowest sample time: 10mS
- Resolution (RBW): 3kHz to 50MHz
- Units: dBm, dBµV, V/m, A/m, W/m²
dBµV/m, W/cm² etc. - Detectors: RMS, Min/Max
- Demodulator: AM, FM
- Input: 50 Ohm N, RF-input (f)
- Accuracy: +/- 2dB (typ.)
- Interface: USB 2.0/1.1/LAN
- Dimensions (L/W/D): 19 inch rack mount
- Weight: 3450gr
- Warranty: 2 years
Integrated PC:
- CPU: Intel Celeron G530 2,4GHz
- RAM: 2x2GB SO-DiMM DDR3, 1066MHz
- HDD: 320GB (5400rpm)
- External Ports: 2x USB 2.0, 2x USB 3.0, 1x Audio, 1x 10/100/1000 Mb/s Ethernet, 1x DVI-I (Analog,Digital), 1x HDMI, 1x eSATA
- Power supply: 19,5V (7,9A max.)
- Operatingsystem: Linux
Highlights:
- Exposure limit calculation and display according to DIN/VDE 0848
- Up to 100x faster sample time as V3 units
- Up to 60dB higher sensitivity as V3 units
- Low noise preamplifier (option)
- 14Bit Dual-ADC
- DDC Hardware-Filter
- 150 MIPS DSP (CPU)
- Real-time remote control via USB /LAN
- Vector (I/Q) measurement
- Real-time Peak Power Detector (option)
- Audio out for the use of PC based FFT analyzer software
- Very thick (3mm) aluminium housing offering very good screening.
- Free MAC OS, Linux and Windows software
Datasheet (pdf)
Application examples
Included in delivery
Options
Accessories
Downloads
- Frequency range: 10MHz to 6GHz
- DANL: -135dBm(1Hz)
- DANL with Preamp: -150dBm(1Hz)
- Max. power at RF input: +10dBm
- Lowest sample time: 10mS
- Resolution (RBW): 3kHz to 50MHz
- Units: dBm, dBµV, V/m, A/m, W/m²
dBµV/m, W/cm² etc. - Detectors: RMS, Min/Max
- Demodulator: AM, FM
- Input: 50 Ohm N, RF-input (f)
- Accuracy: +/- 2dB (typ.)
- Interface: USB 2.0/1.1/LAN
- Dimensions (L/W/D): 19 inch rack mount
- Weight: 3450gr
- Warranty: 2 years
Integrated PC:
- CPU: Intel Celeron G530 2,4GHz
- RAM: 2x2GB SO-DiMM DDR3, 1066MHz
- HDD: 320GB (5400rpm)
- External Ports: 2x USB 2.0, 2x USB 3.0, 1x Audio, 1x 10/100/1000 Mb/s Ethernet, 1x DVI-I (Analog,Digital), 1x HDMI, 1x eSATA
- Power supply: 19,5V (7,9A max.)
- Operatingsystem: Linux
Highlights:
- Exposure limit calculation and display according to DIN/VDE 0848
- Up to 100x faster sample time as V3 units
- Up to 60dB higher sensitivity as V3 units
- Low noise preamplifier (option)
- 14Bit Dual-ADC
- DDC Hardware-Filter
- 150 MIPS DSP (CPU)
- Real-time remote control via USB /LAN
- Vector (I/Q) measurement
- Real-time Peak Power Detector (option)
- Audio out for the use of PC based FFT analyzer software
- Very thick (3mm) aluminium housing offering very good screening.
- Free MAC OS, Linux and Windows software
Application examples
Included in delivery
Options
Accessories
Downloads
