A-INFOMW 90WCAS Right Angle Rectangular Waveguide to Coaxial Adapter (8.2-12.4GHz, WR90 to SMA Female)
ManufacturerA-INFOMW(View more products from this manufacturer)
Model90WCAS
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Adapter Type: Right Angle
Adapter Grade: Standard
Adapter Power Grade: Standard
Waveguide Band: X/ Ku
Waveguide Type: Rectangular
Waveguide Size EIA WR: WR90
Frequency, Min (GHz): 8.2
Frequency, Max (GHz): 12.4
I.L., Typ (dB): 0.18
I.L., Max (dB): 0.23
VSWR, Typ: 1.20:1
VSWR, Max; 1.25:1
Impedance, (Ohm): 50
Power Handling, CW, (W): 50
Power Handling, Peak, (KW): 3
