-Surge Waveform Technical Parameters:
Surge Voltage: 30 V ~ 230 V
Surge Energy: 470 J（＜60J for 70 V voltage）
Rise Time: 1~10 ms
Duration: 50 ms (-0/+5)
Generator Impedance: 500 mΩ（-25/+0 ）
Repetition: 5 s ~ 99 s
Counter: 1~9999
EUT Power Supply: Built-in 28 V, 30 A DC power
Built-in CDN: 30 A
External CDN (option): Max. 400 A
-Spike Waveform Technical Parameters:
Spike Voltage: 50 V ~ 300 V
Spike Energy: ＜3 J
Rise Time: <50 ns
Polarity: Positive, Negative
Repetition: 5 ms~1000 ms
Counter: 1~9999
Oscillatory Frequency: 100 kHz ~ 500 kHz
EUT Power Supply: Built-in 28 V 30 A DC power
Built-in CDN: 30 A
External CDN (option): Max. 400 A
-General Parameters:
Display Screen: 5.7” touch screen
Working Power: AC 110 V/220V（±10%）,50 Hz/60 Hz (AC 220 V 50 Hz in Mainland China)
Fuse: 6 A
Dimension: 19”/4U
Weight: Approx. 28 kg
Ambient Temperature: 15 ℃ ~ 35℃
Relative Humidity: 45%–75%
Atmospheric Pressure: 86 kPa–106 kPa
