3ctest TIS 300 Vehicle Micropulse Generator (30~300V)

- Type A2:

Pulse Amplitude - Vp: 30 V-200 V (±10%)

Rise Time - Tr（Vp): ≤1 μs

Decaying Time Constant – τ: 2.5 μs

Output Impedance - R1: 0.4 Ω

Repetition Frequency: 1/30 Hz

Number of Pulses: 10

Polarity: Positive

- Type B2:

Pulse Amplitude – Vp: 30 V-300 V (±10%)

Rise Time - Tr（Vp): ≤1 μs

Decaying Time Constant –τ: 2000 μs

Output Impedance - R1: 80 Ω

Repetition Frequency: 1/30 Hz

Number of Pulses: 100

Polarity: Negative

- Type C2 (D2):

Pulse Amplitude – Vp: 30 V-200 V (±10%)

Rise Time - Tr（Vp): ≤1 μs

Decaying Time Constant –τ: 2.5 μs

Output Impedance - R1: 0.9 Ω

Repetition Frequency: 1/30 Hz

Number of Pulses: 10

Polarity: Positive

- General Parameter:

Power Supply: AC 110 V/220 V（±10%），50 Hz /60 Hz (±5%)

(In mainland area: AC 220V 50Hz by default）

Ambient Temperature: 15℃–35℃

Relative Humidity: 45%–75%

Atmospheric Pressure: 86 kPa–106 kPa

Dimension: 4U

Weight: Approx. 30 kg
